VM364 Color Machine for Wheat Sorting CE Certificated Optimized Carryover High Rejection Accuracy
VM364 Color Machine Advantages:
1.The international top-level cloud processing system with incomparable arithmetic capability and perfect program design create a new era of large data.
2.The material sorting can be captured dynamically at very high speed as well as analyzed and showed. It realizes truly visualization.
3.The new high-frequency solenoid valve exclusive to color sorter with ultra-low air consumption ensures optimized carryover ratio and high sorting accuracy. It features perfect self-recovery system, low maintenance cost and long lifetime above 10 billion times.
VM364 Color Machine Introduction:
Cereals: corn/barley/wheat/oat/sesame/malt
Nuts & Kernels: sunflower seed/pumpkin seed/watermelon seed/cashew nut/peanut/walnut/pistachio
Seeds: cotton seed/corn seed/wheat seed/pepper seed/onion seed
Our Services :
1.We provide one year guarantee for machine as well as professional training and technical guidance, 7x24h consultation service. which fully reflects our service mode of fast response, timely maintenance and tracking coordination.
2.Anysort currently has more than 120 after-sales service staffs, providing the timely and considerate service for customers
Online Engineering service is always available while providing software checking and maintenance. After-sale service is also provided locally in all countries.
Technical Parameters:
| Model | Throughput (t/h) | Sorting Accuracy (%) | Optimized Carryover | Power (kw) | Power Supply | Dimension L×W×H(mm) | Weight (kg) |
| SQ164 | 0.5-2.0 | ≥99.99 | ＞10:1 | 0.9 | 220V/50HZ | 1410*1800*2180 | 400 |
| SQ364 | 0.5-4 | ≥99.99 | ＞10:1 | 1.8 | 220V/50HZ | 1750*1800*2180 | 650 |
| VM464 | 2.0-8 | ≥99.5 | ＞10:1 | 4 | 220V/50HZ | 2210*1840*2050 | 1270 |
| SQ564 | 5.0-15 | ≥99.99 | ＞10:1 | 2.6 | 220V/50HZ | 2430*1575*2160 | 1350 |
Note: Subject to different raw materials and different impurities percentage in raw materials, parameters listed in above table will change to some extent ,which are references for you choosing a suitable model.
Anysort Product Superiority:
Highly corrosion resistant appearance, nice and durable.
Simple and easy maintenance;
Automatic malfunction indication and one key recovery function;
Easy to replace the light source and magnetic valve.
Example Sorting:
Accepted Wheat
Rejected Wheat
